MPX1D1740L6R8
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 11.5A 15.9 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$5.59
Quote It
Technical Details
- Series:METCOM MPX
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal Composite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):11.5 A
- Current - Saturation (Isat):17A
- Shielding:Shielded
- DC Resistance (DCR):15.9mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:9MHz
- Ratings:-
- Operating Temperature:-55°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.669" L x 0.673" W (17.00mm x 17.10mm)
- Height - Seated (Max):0.157" (4.00mm)
