B82559B6682A027
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 34.5A 1.66 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 621
Can ship immediately
Pricing:
- 1$8.64
Quote It
Technical Details
- Series:ERU27 - Flat Wire Inductor
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±10%
- Current Rating (Amps):34.5 A
- Current - Saturation (Isat):44A
- Shielding:Shielded
- DC Resistance (DCR):1.66mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:1.094" L x 1.016" W (27.80mm x 25.80mm)
- Height - Seated (Max):0.636" (16.15mm)
