CLF7045NIT-220M-D
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.7A 82.8 MOHM
- CategoryFixed Inductors
- Datasheet CLF7045NIT-220M-D Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$1.24
- 1,000$0.56863
- 3,000$0.55086
- 5,000$0.53309
- 10,000$0.51532
Quote It
Technical Details
- Series:CLF-NI-D
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.7 A
- Current - Saturation (Isat):1.7A
- Shielding:Shielded
- DC Resistance (DCR):82.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.291" L x 0.276" W (7.40mm x 7.00mm)
- Height - Seated (Max):0.189" (4.80mm)
