B82462G4223M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.05A 150 MOHM
- CategoryFixed Inductors
- Datasheet B82462G4223M000 Datasheet
-
ECAD Model
- Share
In Stock: 7,231
Can ship immediately
Pricing:
- 1$1.85
- 2,500$0.70954
- 5,000$0.68665
- 12,500$0.66375
Quote It
Technical Details
- Series:B82462G4
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.05 A
- Current - Saturation (Isat):850mA
- Shielding:Shielded
- DC Resistance (DCR):150mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.248" L x 0.248" W (6.30mm x 6.30mm)
- Height - Seated (Max):0.118" (3.00mm)
