7447714681
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 510MA 1.22 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 1,081
Can ship immediately
Pricing:
- 1$2.12
- 500$1.3
- 1,000$1.11
Quote It
Technical Details
- Series:WE-PD Performance
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:680 µH
- Tolerance:±20%
- Current Rating (Amps):510 mA
- Current - Saturation (Isat):710mA
- Shielding:Shielded
- DC Resistance (DCR):1.22Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:2.05MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.394" W (10.00mm x 10.00mm)
- Height - Seated (Max):0.197" (5.00mm)
