MLF2012DR47KT000
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470NH 200MA 500 MOHM
- CategoryFixed Inductors
- Datasheet MLF2012DR47KT000 Datasheet
-
ECAD Model
- Share
In Stock: 102
Can ship immediately
Pricing:
- 1$0.19
- 2,000$0.08157
- 4,000$0.06992
- 6,000$0.06604
- 10,000$0.06215
- 50,000$0.05827
- 100,000$0.05632
Quote It
Technical Details
- Series:MLF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:470 nH
- Tolerance:±10%
- Current Rating (Amps):200 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):500mOhm Max
- Q @ Freq:25 @ 25MHz
- Frequency - Self Resonant:160MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:25 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.057" (1.45mm)
