LQM21PN2R2MEHD
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 1.1A 219 MOHM
- CategoryFixed Inductors
- Datasheet LQM21PN2R2MEHD Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
- 1$0.28
- 3,000$0.10578
- 6,000$0.09956
- 15,000$0.09644
- 30,000$0.09333
- 75,000$0.09022
Quote It
Technical Details
- Series:LQM21
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):450mA
- Shielding:Shielded
- DC Resistance (DCR):219mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:30MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.041" (1.05mm)
