CW201212-R47J
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470NH 250MA 1.72OHM SM
- CategoryFixed Inductors
- Datasheet CW201212-R47J Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$0.35
- 2,000$0.10863
- 4,000$0.1026
- 6,000$0.09656
- 10,000$0.09443
Quote It
Technical Details
- Series:CW201212
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:470 nH
- Tolerance:±5%
- Current Rating (Amps):250 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.72Ohm
- Q @ Freq:33 @ 100MHz
- Frequency - Self Resonant:375MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.083" L x 0.059" W (2.10mm x 1.50mm)
- Height - Seated (Max):0.059" (1.50mm)
