NRS5030T220MMGJ
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.05A 180 MOHM
- CategoryFixed Inductors
- Datasheet NRS5030T220MMGJ Datasheet
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$0.33
- 500$0.1739
- 1,000$0.1332
- 2,500$0.1258
- 5,000$0.1184
- 12,500$0.1147
- 25,000$0.111
- 50,000$0.1073
Quote It
Technical Details
- Series:NR, S Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.05 A
- Current - Saturation (Isat):1.4A
- Shielding:Shielded
- DC Resistance (DCR):180mOhm
- Q @ Freq:-
- Frequency - Self Resonant:13MHz
- Ratings:-
- Operating Temperature:-25°C ~ 120°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.193" L x 0.193" W (4.90mm x 4.90mm)
- Height - Seated (Max):0.118" (3.00mm)
