SRR6038-560Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 850MA 202MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR6038-560Y Datasheet
-
ECAD Model
- Share
In Stock: 7,078
Can ship immediately
Pricing:
- 1$0.84
- 1,000$0.27455
- 3,000$0.2584
- 5,000$0.2527
Quote It
Technical Details
- Series:SRR6038
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±30%
- Current Rating (Amps):850 mA
- Current - Saturation (Isat):900mA
- Shielding:Shielded
- DC Resistance (DCR):202mOhm Max
- Q @ Freq:8.2 @ 2.52MHz
- Frequency - Self Resonant:8.8MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.268" L x 0.268" W (6.80mm x 6.80mm)
- Height - Seated (Max):0.157" (4.00mm)
