CR43NP-4R7MC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 1.15A 108.7 MOHM
- CategoryFixed Inductors
- Datasheet CR43NP-4R7MC Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$0.88
- 1,500$0.4
- 3,000$0.3875
- 7,500$0.375
- 10,500$0.3625
Quote It
Technical Details
- Series:CR43
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±20%
- Current Rating (Amps):1.15 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):108.7mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:49.3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 100°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.189" L x 0.169" W (4.80mm x 4.30mm)
- Height - Seated (Max):0.138" (3.50mm)
