B82432C1224K000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 115MA 7.5 OHM
- CategoryFixed Inductors
- Datasheet B82432C1224K000 Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$1.02
- 2,500$0.41519
- 5,000$0.40222
- 12,500$0.38925
- 25,000$0.37627
Quote It
Technical Details
- Series:SIMID
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±10%
- Current Rating (Amps):115 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):7.5Ohm Max
- Q @ Freq:30 @ 796kHz
- Frequency - Self Resonant:6MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:1812 (4532 Metric)
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
