SLF7032T-220MR96-2PF
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 960MA 132 MOHM
- CategoryFixed Inductors
- Datasheet SLF7032T-220MR96-2PF Datasheet
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$0.94
- 1,000$0.432
- 3,000$0.4185
- 5,000$0.405
- 10,000$0.3915
- 25,000$0.378
Quote It
Technical Details
- Series:SLF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):960 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):132mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
- Height - Seated (Max):0.134" (3.40mm)
