SRN1060-221M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 1A 460 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRN1060-221M Datasheet
-
ECAD Model
- Share
In Stock: 1,901
Can ship immediately
Pricing:
- 1$0.88
- 600$0.357
- 1,200$0.289
- 3,000$0.272
- 6,000$0.266
Quote It
Technical Details
- Series:SRN1060
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±20%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):1.2A
- Shielding:Semi-Shielded
- DC Resistance (DCR):460mOhm Max
- Q @ Freq:13 @ 2.52MHz
- Frequency - Self Resonant:3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.386" W (10.00mm x 9.80mm)
- Height - Seated (Max):0.236" (6.00mm)
