SRP3020TA-2R2M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 3.5A 75 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP3020TA-2R2M Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$1.23
Quote It
Technical Details
- Series:SRP3020TA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Carbonyl Powder
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):3.5 A
- Current - Saturation (Isat):3.7A
- Shielding:Shielded
- DC Resistance (DCR):75mOhm Max
- Q @ Freq:10 @ 100kHz
- Frequency - Self Resonant:45MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD
- Supplier Device Package:2-SMD
- Size / Dimension:0.138" L x 0.126" W (3.50mm x 3.20mm)
- Height - Seated (Max):0.079" (2.00mm)
