B82442T1106K050
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10MH 46MA 112 OHM SMD
- CategoryFixed Inductors
- Datasheet B82442T1106K050 Datasheet
-
ECAD Model
- Share
In Stock: 197
Can ship immediately
Pricing:
- 1$1.31
- 1,500$0.68382
- 3,000$0.66246
- 7,500$0.64108
- 10,500$0.61972
Quote It
Technical Details
- Series:SIMID
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 mH
- Tolerance:±10%
- Current Rating (Amps):46 mA
- Current - Saturation (Isat):81mA
- Shielding:Unshielded
- DC Resistance (DCR):112Ohm Max
- Q @ Freq:25 @ 79.6kHz
- Frequency - Self Resonant:500kHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:79.6 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:2220 (5650 Metric)
- Size / Dimension:0.220" L x 0.197" W (5.60mm x 5.00mm)
- Height - Seated (Max):0.209" (5.30mm)
