SRP4020FA-4R7M

Technical Details

• Series:SRP4020FA
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Iron Powder
• Inductance:4.7 µH
• Tolerance:±20%
• Current Rating (Amps):5.1 A
• Current - Saturation (Isat):2.7A
• Shielding:Shielded
• DC Resistance (DCR):57.2mOhm Max

• Q @ Freq:15 @ 100kHz
• Frequency - Self Resonant:25MHz
• Ratings:AEC-Q200
• Operating Temperature:-55°C ~ 155°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.161" L x 0.161" W (4.10mm x 4.10mm)
• Height - Seated (Max):0.083" (2.10mm)
