SRR6603-470ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 500MA 230MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR6603-470ML Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$1.31
- 600$0.5202
- 1,200$0.4624
- 3,000$0.4522
Quote It
Technical Details
- Series:SRR6603
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:47 µH
- Tolerance:±20%
- Current Rating (Amps):500 mA
- Current - Saturation (Isat):240mA
- Shielding:Shielded
- DC Resistance (DCR):230mOhm Max
- Q @ Freq:40 @ 100kHz
- Frequency - Self Resonant:20MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.260" L x 0.173" W (6.60mm x 4.40mm)
- Height - Seated (Max):0.118" (3.00mm)
