ETQ-P5M2R5YFC
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.5UH 18.1A 5.9 MOHM
- CategoryFixed Inductors
- Datasheet ETQ-P5M2R5YFC Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$1.66
- 500$0.85656
- 1,000$0.76139
- 2,500$0.73759
- 5,000$0.7138
- 12,500$0.69001
Quote It
Technical Details
- Series:PCC-M1054M
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal Composite
- Inductance:2.5 µH
- Tolerance:±20%
- Current Rating (Amps):18.1 A
- Current - Saturation (Isat):27.2A
- Shielding:Shielded
- DC Resistance (DCR):5.9mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:-
- Size / Dimension:0.421" L x 0.394" W (10.70mm x 10.00mm)
- Height - Seated (Max):0.213" (5.40mm)
