1025-22K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.2UH 620MA 180 MOHM
- CategoryFixed Inductors
- Datasheet 1025-22K Datasheet
-
ECAD Model
- Share
In Stock: 246
Can ship immediately
Pricing:
- 1$1.8
- 1,000$0.4112
- 3,000$0.39835
- 5,000$0.3855
- 10,000$0.37265
- 25,000$0.3598
Quote It
Technical Details
- Series:Military, MIL-PRF-M15305, MS75084
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Iron
- Inductance:1.2 µH
- Tolerance:±10%
- Current Rating (Amps):620 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):180mOhm Max
- Q @ Freq:25 @ 7.9MHz
- Frequency - Self Resonant:150MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:7.9 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.095" Dia x 0.250" L (2.41mm x 6.35mm)
- Height - Seated (Max):-
