SRP6060FA-100M

Technical Details

• Series:SRP6060FA
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Iron Powder
• Inductance:10 µH
• Tolerance:±20%
• Current Rating (Amps):7 A
• Current - Saturation (Isat):7.6A
• Shielding:Shielded
• DC Resistance (DCR):29.3mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:12MHz
• Ratings:AEC-Q200
• Operating Temperature:-55°C ~ 155°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.260" L x 0.252" W (6.60mm x 6.40mm)
• Height - Seated (Max):0.236" (6.00mm)
