1422441C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 4.1A 73 MOHM TH
- CategoryFixed Inductors
- Datasheet 1422441C Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$2.62
- 5$2.61
- 10$2.59
- 25$2.56
- 50$2.51
- 100$2.38
- 250$2.23
- 500$2.08
- 1,000$2.0615
Quote It
Technical Details
- Series:1400
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:220 µH
- Tolerance:±10%
- Current Rating (Amps):4.1 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):73mOhm Max
- Q @ Freq:33 @ 100kHz
- Frequency - Self Resonant:2.3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:1.035" Dia (26.30mm)
- Height - Seated (Max):0.787" (20.00mm)
