MHQ1005P15NJT000
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15NH 400MA 280 MOHM
- CategoryFixed Inductors
- Datasheet MHQ1005P15NJT000 Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
- 1$0.19
- 10,000$0.08181
- 30,000$0.07917
- 50,000$0.07653
- 100,000$0.07389
Quote It
Technical Details
- Series:MHQ-P
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ceramic, Non-Magnetic
- Inductance:15 nH
- Tolerance:±5%
- Current Rating (Amps):400 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):280mOhm Max
- Q @ Freq:23 @ 250MHz
- Frequency - Self Resonant:2.3GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
- Height - Seated (Max):0.024" (0.60mm)
