HK212556NJ-T
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56NH 300MA 750 MOHM
- CategoryFixed Inductors
- Datasheet HK212556NJ-T Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$0.2
- 3,000$0.07086
- 6,000$0.06693
- 15,000$0.06299
- 30,000$0.06102
- 75,000$0.05905
- 150,000$0.05708
Quote It
Technical Details
- Series:HK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:56 nH
- Tolerance:±5%
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):750mOhm Max
- Q @ Freq:18 @ 100MHz
- Frequency - Self Resonant:800MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.047" (1.20mm)
