36401E5N6ATDF

Technical Details

• Series:3640, Sigma Inductors
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Thin Film
• Material - Core:-
• Inductance:5.6 nH
• Tolerance:±0.2nH
• Current Rating (Amps):280 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):850mOhm Max

• Q @ Freq:13 @ 500MHz
• Frequency - Self Resonant:6GHz
• Ratings:-
• Operating Temperature:-
• Inductance Frequency - Test:500 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0402 (1005 Metric)
• Supplier Device Package:0402 (1005 Metric)
• Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
• Height - Seated (Max):0.015" (0.37mm)
