CBC2016T4R7M
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 530MA 481 MOHM
- CategoryFixed Inductors
- Datasheet CBC2016T4R7M Datasheet
-
ECAD Model
- Share
In Stock: 196
Can ship immediately
Pricing:
- 1$0.24
- 10$0.21216
- 100$0.14573
- 500$0.12453
- 1,000$0.09539
Quote It
Technical Details
- Series:CB, C Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±20%
- Current Rating (Amps):530 mA
- Current - Saturation (Isat):550mA
- Shielding:Unshielded
- DC Resistance (DCR):481mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:45MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0806 (2016 Metric)
- Supplier Device Package:0806 (2016 Metric)
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.071" (1.80mm)
