NRS6010T1R5MMGF

Technical Details

• Series:NR, S Type
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1.5 µH
• Tolerance:±20%
• Current Rating (Amps):1.9 A
• Current - Saturation (Isat):2.4A
• Shielding:Shielded
• DC Resistance (DCR):108mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:77MHz
• Ratings:-
• Operating Temperature:-25°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:2304 (6010 Metric)
• Supplier Device Package:-
• Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
• Height - Seated (Max):0.039" (1.00mm)
