B82144F2183K000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 2.2A 155 MOHM TH
- CategoryFixed Inductors
- Datasheet B82144F2183K000 Datasheet
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
- 1$0.66
- 1,500$0.3502
- 3,000$0.3296
- 7,500$0.3193
- 10,500$0.309
Quote It
Technical Details
- Series:LBC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±10%
- Current Rating (Amps):2.2 A
- Current - Saturation (Isat):2.25A
- Shielding:Unshielded
- DC Resistance (DCR):155mOhm Max
- Q @ Freq:50 @ 252kHz
- Frequency - Self Resonant:12MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.256" Dia x 0.362" L (6.50mm x 9.20mm)
- Height - Seated (Max):-
