PM105-100M-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 2.6A 60 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM105-100M-RC Datasheet
-
ECAD Model
- Share
In Stock: 273
Can ship immediately
Pricing:
- 1$1.33
- 500$0.5814
- 1,000$0.5168
- 2,500$0.5054
Quote It
Technical Details
- Series:PM105
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):2.6 A
- Current - Saturation (Isat):5.1A
- Shielding:Unshielded
- DC Resistance (DCR):60mOhm
- Q @ Freq:30 @ 2.52MHz
- Frequency - Self Resonant:21MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.386" L x 0.386" W (9.80mm x 9.80mm)
- Height - Seated (Max):0.228" (5.80mm)
