SDR2207-220YL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 4A 39.4 MOHM SMD
- CategoryFixed Inductors
- Datasheet SDR2207-220YL Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$1.35
- 250$1.14752
- 500$0.98357
- 750$0.92893
- 1,250$0.87429
- 2,500$0.855
Quote It
Technical Details
- Series:SDR2207
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±15%
- Current Rating (Amps):4 A
- Current - Saturation (Isat):6.5A
- Shielding:Unshielded
- DC Resistance (DCR):39.4mOhm Max
- Q @ Freq:27 @ 3MHz
- Frequency - Self Resonant:14MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.866" L x 0.591" W (22.00mm x 15.00mm)
- Height - Seated (Max):0.307" (7.80mm)
