MPCH1040LR36

Technical Details

• Series:MPCH
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:-
• Material - Core:Metal Composite
• Inductance:360 nH
• Tolerance:±20%
• Current Rating (Amps):28 A
• Current - Saturation (Isat):24A
• Shielding:Shielded
• DC Resistance (DCR):0.88mOhm

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-20°C ~ 120°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.453" L x 0.394" W (11.50mm x 10.00mm)
• Height - Seated (Max):0.157" (4.00mm)
