B82479A1683M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68UH 2.3A 130 MOHM SMD
- CategoryFixed Inductors
- Datasheet B82479A1683M000 Datasheet
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$1.74
- 250$0.96488
- 500$0.91128
- 750$0.85767
- 1,250$0.83087
- 2,500$0.80407
- 6,250$0.77727
- 12,500$0.75046
Quote It
Technical Details
- Series:B82479A1
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:68 µH
- Tolerance:±20%
- Current Rating (Amps):2.3 A
- Current - Saturation (Isat):3.5A
- Shielding:Unshielded
- DC Resistance (DCR):130mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.730" L x 0.600" W (18.54mm x 15.24mm)
- Height - Seated (Max):0.280" (7.11mm)
