RL895-101K-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 900MA 190MOHM TH
- CategoryFixed Inductors
- Datasheet RL895-101K-RC Datasheet
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$1.39
- 10$1.29568
- 100$0.93713
- 500$0.71776
- 1,000$0.63801
- 2,500$0.62394
Quote It
Technical Details
- Series:RL895
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±10%
- Current Rating (Amps):900 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):190mOhm Max
- Q @ Freq:25 @ 796kHz
- Frequency - Self Resonant:4MHz
- Ratings:-
- Operating Temperature:-30°C ~ 100°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder (Open)
- Supplier Device Package:-
- Size / Dimension:0.307" Dia (7.80mm)
- Height - Seated (Max):0.374" (9.50mm)
