LQM21PN3R3NG0D

Technical Details

• Series:LQM21
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Multilayer
• Material - Core:Ferrite
• Inductance:3.3 µH
• Tolerance:±30%
• Current Rating (Amps):800 mA
• Current - Saturation (Isat):-
• Shielding:Shielded
• DC Resistance (DCR):207mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:30MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:1 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0805 (2012 Metric)
• Supplier Device Package:0805 (2012 Metric)
• Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
• Height - Seated (Max):0.039" (1.00mm)
