NLV32T-560J-EFD
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 55MA 8 OHM SMD
- CategoryFixed Inductors
- Datasheet NLV32T-560J-EFD Datasheet
-
ECAD Model
- Share
In Stock: 230
Can ship immediately
Pricing:
- 1$0.32
- 2,000$0.12851
- 4,000$0.12137
- 6,000$0.11423
- 10,000$0.11066
- 50,000$0.10353
- 100,000$0.09995
Quote It
Technical Details
- Series:NLV-EFD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±5%
- Current Rating (Amps):55 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):8Ohm Max
- Q @ Freq:30 @ 2.52MHz
- Frequency - Self Resonant:13MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1210 (3225 Metric)
- Supplier Device Package:1210
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.094" (2.40mm)
