MLP2520V4R7ST0S1
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 800MA 286 MOHM
- CategoryFixed Inductors
- Datasheet MLP2520V4R7ST0S1 Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$0.4
- 3,000$0.15032
- 6,000$0.14147
- 15,000$0.13705
- 30,000$0.13263
- 75,000$0.12821
Quote It
Technical Details
- Series:MLP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±20%
- Current Rating (Amps):800 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):286mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:2 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.047" (1.20mm)
