NRS6020T100MMGGV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 1.5A 150 MOHM SMD
- CategoryFixed Inductors
- Datasheet NRS6020T100MMGGV Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$0.61
- 2,500$0.24489
- 5,000$0.23723
- 12,500$0.22958
- 25,000$0.22193
Quote It
Technical Details
- Series:NR, S Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):1.5 A
- Current - Saturation (Isat):1.9A
- Shielding:Shielded
- DC Resistance (DCR):150mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:18MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
- Height - Seated (Max):0.079" (2.00mm)
