B82422H1332J000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 770MA 180 MOHM
- CategoryFixed Inductors
- Datasheet B82422H1332J000 Datasheet
-
ECAD Model
- Share
In Stock: 257
Can ship immediately
Pricing:
- 1$0.75
- 2,000$0.31505
Quote It
Technical Details
- Series:SIMID
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±5%
- Current Rating (Amps):770 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):180mOhm Max
- Q @ Freq:10 @ 2.52MHz
- Frequency - Self Resonant:70MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:1210 (3225 Metric)
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.094" (2.40mm)
