SRU3014-2R0Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2UH 1.1A 95 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRU3014-2R0Y Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$0.89
- 1,200$0.27455
- 3,600$0.2584
- 6,000$0.2527
Quote It
Technical Details
- Series:SRU3014
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2 µH
- Tolerance:±30%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):1.3A
- Shielding:Shielded
- DC Resistance (DCR):95mOhm Max
- Q @ Freq:10 @ 7.96MHz
- Frequency - Self Resonant:110MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.138" L x 0.130" W (3.50mm x 3.30mm)
- Height - Seated (Max):0.063" (1.60mm)
