IHLP2525BDER1R5M01
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 7.5A 21.2 MOHM
- CategoryFixed Inductors
- Datasheet IHLP2525BDER1R5M01 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$1.26
- 2,000$1.209
- 4,000$1.17
- 6,000$1.131
Quote It
Technical Details
- Series:IHLP-2525BD-01
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):7.5 A
- Current - Saturation (Isat):15A
- Shielding:Shielded
- DC Resistance (DCR):21.2mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.270" L x 0.255" W (6.86mm x 6.47mm)
- Height - Seated (Max):0.094" (2.40mm)
