SRR1050A-121Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 120UH 1.18A 305MOHM SM
- CategoryFixed Inductors
- Datasheet SRR1050A-121Y Datasheet
-
ECAD Model
- Share
In Stock: 149
Can ship immediately
Pricing:
- 1$1.19
- 700$0.4743
- 1,400$0.4216
- 3,500$0.4123
Quote It
Technical Details
- Series:SRR1050A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:120 µH
- Tolerance:±30%
- Current Rating (Amps):1.18 A
- Current - Saturation (Isat):1.28A
- Shielding:Shielded
- DC Resistance (DCR):305mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:3.8MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.402" L x 0.394" W (10.20mm x 10.00mm)
- Height - Seated (Max):0.201" (5.10mm)
