SPM4020T-R47M-LR
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470NH 8.7A 11.8 MOHM
- CategoryFixed Inductors
- Datasheet SPM4020T-R47M-LR Datasheet
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$1.36
- 500$0.69858
- 1,000$0.62096
- 2,500$0.60156
- 5,000$0.58215
- 12,500$0.56274
Quote It
Technical Details
- Series:SPM-LR
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:470 nH
- Tolerance:±20%
- Current Rating (Amps):8.7 A
- Current - Saturation (Isat):14.1A
- Shielding:Shielded
- DC Resistance (DCR):11.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.173" L x 0.161" W (4.40mm x 4.10mm)
- Height - Seated (Max):0.079" (2.00mm)
