744028006
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 750MA 400 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 120
Can ship immediately
Pricing:
- 1$0.79
- 1,500$0.79
Quote It
Technical Details
- Series:WE-TPC
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±30%
- Current Rating (Amps):750 mA
- Current - Saturation (Isat):550mA
- Shielding:Shielded
- DC Resistance (DCR):400mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:60MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:2828
- Size / Dimension:0.110" L x 0.110" W (2.80mm x 2.80mm)
- Height - Seated (Max):0.047" (1.20mm)
