RLF10160T-470M1R5-D
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 1.5A 111.6 MOHM
- CategoryFixed Inductors
- Datasheet RLF10160T-470M1R5-D Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
- 1$3.05
- 500$1.59556
- 1,000$1.45477
- 2,500$1.40784
- 5,000$1.36092
Quote It
Technical Details
- Series:RLF-D
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:47 µH
- Tolerance:±20%
- Current Rating (Amps):1.5 A
- Current - Saturation (Isat):2.4A
- Shielding:Shielded
- DC Resistance (DCR):111.6mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.402" L x 0.394" W (10.20mm x 10.00mm)
- Height - Seated (Max):0.252" (6.40mm)
