9220-28-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1MH 78MA 16.5 OHM TH
- CategoryFixed Inductors
- Datasheet 9220-28-RC Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$2.22
- 10$2.04912
- 100$1.43394
- 500$1.16077
- 1,000$1.06838
Quote It
Technical Details
- Series:9220
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 mH
- Tolerance:±5%
- Current Rating (Amps):78 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):16.5Ohm Max
- Q @ Freq:60 @ 7.9MHz
- Frequency - Self Resonant:2.8MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:7.9 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.190" Dia x 0.440" L (4.83mm x 11.18mm)
- Height - Seated (Max):-
