S14100034
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 18A 4.5 MOHM TH
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$4.18
- 10$3.976
- 16$3.58375
- 32$3.315
- 64$3.02406
- 256$2.68801
Quote It
Technical Details
- Series:WE-FI
- Package:Tray
- Part Status:Active
- Type:Toroidal
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):18 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):4.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Horizontal (Open)
- Supplier Device Package:-
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):0.689" (17.50mm)
