PM5022-151K-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 150UH 1.4A 270MOHM SMD
- CategoryFixed Inductors
- Datasheet PM5022-151K-RC Datasheet
-
ECAD Model
- Share
In Stock: 239
Can ship immediately
Pricing:
- 1$0.94
- 250$0.48196
- 500$0.4131
- 750$0.39015
- 1,250$0.3672
- 2,500$0.3591
Quote It
Technical Details
- Series:PM5022
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:150 µH
- Tolerance:±10%
- Current Rating (Amps):1.4 A
- Current - Saturation (Isat):2.6A
- Shielding:Unshielded
- DC Resistance (DCR):270mOhm Max
- Q @ Freq:23 @ 5MHz
- Frequency - Self Resonant:796kHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.720" L x 0.551" W (18.30mm x 14.00mm)
- Height - Seated (Max):0.272" (6.90mm)
