HCM1A1307V2-220-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 6A 33.1 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$2.11
Quote It
Technical Details
- Series:HCM1AV2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Iron Powder
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):6 A
- Current - Saturation (Isat):8A
- Shielding:Shielded
- DC Resistance (DCR):33.1mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:5MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.530" L x 0.496" W (13.45mm x 12.60mm)
- Height - Seated (Max):0.256" (6.50mm)
