744776182
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 82UH 1.11A 250 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$1.602
- 500$1.602
Quote It
Technical Details
- Series:WE-PD2
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:82 µH
- Tolerance:±10%
- Current Rating (Amps):1.11 A
- Current - Saturation (Isat):1.17A
- Shielding:Unshielded
- DC Resistance (DCR):250mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:8MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:10 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.354" W (10.00mm x 9.00mm)
- Height - Seated (Max):0.232" (5.90mm)
