2204-V-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 10.8A 9 MOHM TH
- CategoryFixed Inductors
- Datasheet 2204-V-RC Datasheet
-
ECAD Model
- Share
In Stock: 168
Can ship immediately
Pricing:
- 1$4.22
- 10$3.86463
- 100$2.52978
- 500$2.24869
- 1,000$2.19909
Quote It
Technical Details
- Series:2200
- Package:Bulk
- Part Status:Active
- Type:Toroidal
- Material - Core:Iron Powder
- Inductance:18 µH
- Tolerance:±15%
- Current Rating (Amps):10.8 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):9mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical (Open)
- Supplier Device Package:-
- Size / Dimension:0.950" Dia x 0.550" W (24.13mm x 13.97mm)
- Height - Seated (Max):-
